Walk‑behind Pallet Stacker, 1.5 Ton

Home / Products /
,
/
Walk‑behind Pallet Stacker, 1.5 Ton

Walk‑behind Pallet Stacker, 1.5 Ton

Engineered for construction, agriculture, and multi-scenario operations.
Powerful Engine Output for stable performance even under heavy load.
Multi-Function Capability with a wide range of attachments.
Compact Design & Agile Control suitable for narrow job sites.
Low Fuel Consumption & High Reliability for reduced operation cost.
Enhanced Safety Protection including ROPS, stability system, and reinforced structure.
Get a Quote
官网询盘
1.5T Walk‑behind Full‑electric Stacker Technical Parameters
Item Specification Unit
Load Capacity 1.5 T
Operation Type Walk‑behind full‑electric type /
Braking Mode Electronic brake /
Machine Weight (Basic) Approx. 510 KG
Fork Ground Clearance 85 mm
Drive Motor Power 48V1500W /
Lift Pump Motor Power 48V2200W /
Fork Size 115018050 mm
Fork Outer Width 700 mm
Fork Inner Width 340 mm
Fork Length 1150 mm
Overall Machine Length 1960 mm
Overall Machine Width 790 mm
Mast Height Options
Item Lifting Height Static Height Unit
Two‑stage Mast 2000 1560 mm
Two‑stage Mast 2500 1760 mm
Two‑stage Mast 3000 2000 mm
Two‑stage Mast 3500 2300 mm
Two‑stage Mast 4000 2550 mm
Three‑stage Mast 3500 1800 mm
Three‑stage Mast 4000 1960 mm
Three‑stage Mast 4500 2100 mm
Three‑stage Mast 5000 2330 mm
Three‑stage Mast 5500 2500 mm
Remarks Lifting height can be customized / /

Strong Power

Delivers stable and efficient engine output, allowing the machine to handle heavy workloads with consistent performance across various job sites.

Precise Control

Advanced hydraulic and control systems provide smooth, highly responsive handling, making all machine operations much easier and improving overall work accuracy.

Durable Build

Reinforced frame and high-strength components ensure long-term durability, excellent wear resistance, and reliable performance under tough conditions.

Versatile Use

Compatible with multiple attachments, the machine adapts to construction, landscaping, agriculture, and material handling tasks efficiently.

FAQ

How long is the product warranty?

All Shanghai Jinglifeng machinery comes with a standard one-year warranty. Key spare parts can have extended coverage with global after-sales support.

Excavators are suitable for earthwork, construction, and landscaping; skid steer loaders for material handling, cleaning, and landscaping; lawn mowers for lawns, fields, and gardens.

Yes, our machinery is ergonomically designed for easy operation, and manuals and video tutorials help users get started quickly.

Yes, routine inspection and maintenance are recommended, including lubrication, oil changes, and checking wear parts to ensure long-term stable operation.

Shanghai Jinglifeng machinery uses efficient engines with low-noise design and meets international emission standards, suitable for various work environments.

Yes, we provide a full set of original spare parts, with fast logistics delivery to keep machines running continuously.
